DOUBLE GRIDER EOT CRANE
DOUBLE GIRDER E.O.T. CRANE
Double Girder EOT Cranes are designed and manufactured as per the specific requirements of customers and site conditions. These cranes are ideal for Power Houses, workshops, and heavy industrial units for handling large equipment, coils, and other heavy materials.
We also offer special-purpose cranes for handling liquid metals in hot and hazardous conditions. Flame-proof cranes are available as per site requirements.
100T
Max Capacity
4500mm
Head Room
20m
Span
| Capacity (Tonnes) | Span (m) | Head Room (mm) | Wheel Base (mm) | Hook Approach (mm) | End Clearance (mm) | Wheel Load (t) | Total Weight (t) |
|---|---|---|---|---|---|---|---|
| 5 | 10 | 1600 | 380 | 900 | 250 | 5.8 | 10.0 |
| 10 | 10 | 1800 | 380 | 1000 | 250 | 9.5 | 13.0 |
| 20 | 15 | 2400 | 420 | 1100 | 300 | 18.4 | 24.0 |
| 40 | 15 | 3000 | 480 | 1300 | 325 | 31.9 | 35.5 |
| 60 | 15 | 3800 | 560 | 1600 | 400 | 49.5 | 60.0 |
| 100 | 20 | 4500 | 620 | 1900 | 450 | 61.0 | 110.0 |
